| CPU |
LGA1851 socket: Support for Intel® Core™ Ultra Processors, L3 cache varies with CPU |
| Chipset |
Intel® Z890 Express Chipset |
| Memory |
Supports DDR5 9500(O.C) / 9466(O.C) / 9333(O.C) / 9200(O.C) / 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules. 4 x DDR5 DIMM sockets, up to 256 GB. |
| Onboard Graphics |
Integrated Graphics Processor-Intel® HD Graphics, 2 x Thunderbolt™ 4, 1 x HDMI, supports up to triple-display. |
| Audio |
Realtek® ALC1220 CODEC, High Definition Audio, 2/4/5.1/7.1-channel, S/PDIF Out |
| LAN |
Realtek® 5GbE LAN chip |
| Wireless Communication |
Intel® Wi-Fi 7 BE200, Bluetooth 5.4 |
| Expansion Slots |
1 x PCI Express x16 slot (PCIe 5.0), 1 x PCI Express x16 slot (PCIe 4.0), 1 x PCI Express x16 slot (PCIe 4.0 x1) |
| Storage Interface |
CPU: 2 x M.2 (PCIe 5.0/4.0), Chipset: 3 x M.2 (PCIe 4.0), 4 x SATA 6Gb/s connectors |
| USB Ports |
2 x Thunderbolt™ 4 (USB Type-C®), 1 x USB Type-C® (USB 3.2 Gen 2×2), 2 x USB 3.2 Gen 2 Type-A, 6 x USB 3.2 Gen 1, 8 x USB 2.0 |
| Internal I/O Connectors |
24-pin ATX, 2 x 8-pin ATX 12V, CPU fan headers, system fan headers, RGB headers, M.2 connectors, SATA, TPM, and more |
| Back Panel Connectors |
USB 2.0/3.2, Thunderbolt™ 4, RJ-45, audio jacks, S/PDIF Out |
| I/O Controller |
iTE® I/O Controller Chip |
| H/W Monitoring |
Voltage, temperature, fan speed, noise detection |
| BIOS |
256 Mbit flash, AMI UEFI BIOS, ACPI 5.0 |
| Unique Features |
GIGABYTE Control Center, Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software |
Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System |
Windows 11 64-bit |
| Form Factor |
ATX, 30.5cm x 24.4cm |
